AITR Medical Isolation Transformer
AITR Medical Isolation Transformer
● Isolating transformers for medical IT systems
● Double insulation treatment, Electrostatic shielding layer
● PT100 temperature sensor
● Rated power: 3.15…10KVA
|
Rated Capacity |
3.15kVA/5kVA/6.3kVA/8kVA/10kVA |
|
Frequency |
50/60Hz |
|
Rated input voltage |
230V |
|
The output voltage |
230V/115V |
|
Inrush current(IE) |
<12In |
|
Leakage Current |
<200uA |
|
No-load output voltage(UO) |
<235V |
|
No-load output current(IO) |
<3% In |
|
Short-circuit voltage |
<3% Un |
|
Efficiency |
>96% |
|
Maximum ambient temperature |
<40℃ |
|
No-load temperature rise |
<33℃ |
|
Full load temperature rise |
<76℃ |
|
Withstand voltage |
4200V/Min |
|
Insulation Class |
H |
|
Noise Level |
<40dB (A) |
