PARAMETER NAME

AWT100-4G

AWT100-NB

AWT100-2G

AWT100-LoRa
AWT100-LW

WORKING FREQUENCY

LTE-FDD B1 B3 B5 B8
LTE-TDD B34 B38 B39 B40 B41
CDMA B1 B5 B8
GSM 900/1800M

H-FDD B1 B3 B8 B5 B20

GSM 850
EGSM 900
DCS 1800
PCS 1900

LoRa 460 510MHz

TRANSMISSION RATE

LTE-FDD
Maximum downlink rate 150Mbps
Maximum uplink rate 50Mbps
LTE-TDD
Maximum downlink rate130Mbps
Maximum uplink rate 35Mbps
CDMA
Maximum downlink rate 3.1Mbps
Maximum uplink rate 1.8Mbps
GSM
Maximum downlink rate 107Kbps
Maximum uplink rate 85.6Kbps

Maximum downlink rate 25.2Kbps
Maximum uplink rate 15.62Kbps

GPRS
Maximum downlink rate 85.6kbps
Maximum uplink rate 85.6kbps

LoRa 62.5kbps

DOWNLINK

RS485 Communication

UPLINK

4G Communication

NB-IoT Communication

2G Communication

LoRa Communication

SIM CARD VOLTAGE

3V, 1.8V

/

WORKING CURRENT

Static power: ≤1W，Transient power consumption: ≤3W

Static power: ≤0.5W，
Transient power consumption: ≤1W

ANTENNA INTERFACE

50Ω/SMA（Faucet）

SERIAL PORT TYPE

RS-485

BAUD RATE

4800bps、9600bps、19200bps、38400bps（default 9600bps）

OPERATING VOLTAGE

DC24V or AC/DC220V

OPERATING TEMPERATURE

-10℃～55℃

STORAGE TEMPERATURE

-40℃～85℃

HUMIDITY RANGE

0～95% Non-condensing
